Product Overview
Analog Devices AD7516JN CMOS Analog Switch IC (DIP-16)
What it is:
AD7516JN is a CMOS analog switch IC from Analog Devices.
What it’s used for:
Allows switching of analog signals between multiple channels using digital control inputs.
Key Features:
- Low power CMOS, bidirectional signal handling, multiple channels, simple control
Applications:
- Data acquisition systems, audio routing, test equipment, instrumentation
Technical Specifications:
| Part Number | AD7516JN |
| Function | Quad SPST (Single-Pole Single-Throw) Analog Switch |
| Package Type | DIP-16 |
| Pin Count | 16 pins |
| Mounting Type | Through-hole |
| Technology | CMOS |
| Weight | ~0.2 oz |
